Slimline Beverage Refrigerator with Auto Defrost 2–8℃ 268L
Model: NW-LG268
- Model: NW-LG268
- Product Type: cooler
- Door Type: glass door
- Height: taller than 1.5m/4.9ft
Door Style: 1 Glass Swing Door
Temp. Range: 0~10 ℃
Internal Capacity: 268L
Net Weight: 64kg
Package Weight: 72kg
Packed Dimension: 585x625x1904mm
Unit Dimension: 530*590*1845mm
Technical Data
Product Details
Features
Model: NW-LG268/300/350/430.
Storage capacity: 268/300/350/430 liters.
Direct cooling system.
For drink and beverage display.
Physical temperature control.
Several size options are available.
Shelves are adjustable.
High-performance and long lifespan.
Durable tempered glass swing door.
The door auto-closing type is optional.
The door lock is optional as request.
Stainless steel exterior and aluminum interior.
Finished with powder coating.
White is the standard color, other colors are customizable.
Low noise and energy consumption.
With a build-in evaporator.
Bottom wheels for flexible placement.
The top light box is customizable for advertisement.
Specifications
MODEL | NW-LG268 | NW-LG300 | NW-LG350 | NW-LG430 | |
System | Net (Liters) | 268 | 300 | 350 | 430 |
Net (CB FEET) | 8.8 | 10.6 | 12.4 | 15.2 | |
Cooling system | Direct cooling | Direct cooling | Direct cooling | Direct cooling | |
Auto-Defrost | No | ||||
Control system | Mechanical | ||||
Dimensions WxDxH (mm) | External | 530x595x1745 | 620x595x1845 | 620x595x1935 | 620x690x2073 |
Internal | 440x430x1190 | 530x430x1290 | 530x470x1380 | 530*545*1495 | |
Packing | 595x625x1804 | 685x625x1904 | 685x665x1994 | 685x725x2132 | |
Weight (kg) | Net | 62 | 68 | 75 | 85 |
Gross | 72 | 89 | 85 | 95 | |
Doors | Door Type | Swing Door | |||
Frame & Handle | PVC | ||||
Glass Type | Tempered Glass | ||||
Auto Closing | Optional | ||||
Lock | Yes | ||||
Insulation (CFC-free) | Type | C-pentane | |||
Dimensions (mm) | 50(average) | 50(average) | 50(average) | 50(average) | |
Equipment | Adjustable shelves (pcs) | 3 | 4 | 4 | 2 |
Rear Wheels | 2 pcs (Adjustable) | ||||
Front Feet | 2 pcs (Wheels for Option) | ||||
Internal light vert./hor.* | Horizontal*1 | Vertical*1 | |||
Specification | Voltage/Frequency | 220~240V/50HZ | |||
Power Consumption (w) | 160 | 185 | 205 | 250 | |
Amp. Consumption (A) | 1.17 | 1.46 | 1.7 | 2.3 | |
Energy Consumption (kWh/24h) | 1.4 | 1.68 | 1.8 | 2.3 | |
Cabinet Tem. 0C | 0~10°C | ||||
Temp. Control | Physical | ||||
Climate Class As per EN441-4 | Class 3 | ||||
Max. Ambient Temp. °C | 38°C | ||||
Components | Refrigerant (CFC-free) gr | R134a/115g | R134a/140g | R134a/210g | R134a/230g |
Outer Cabinet | Steel | ||||
Inside Cabinet | Aluminum | ||||
Condenser | Backside Mash Wire | ||||
Evaporator | Build-in Insulation | ||||
Evaporator fan | 14W Square fan |
